SB001 - POSTMOUNT ADAPTER +43 mm.
21 gr.
Applications :
- MTB
- E-BIKES
Accessories
SB001/002/003/004/005: caliper adapter for oversize brake discs for radial type system (postmount). This assembly may use 4 bolts, 2 for the brake caliper and other 2 for fork (front) or bike frame (rear). Two bolts included. It is recommended to assembly by a specialist and not use axial caliper adapters (IS system) for discs bigger than ø180mm. GALFER decline all responsability in case of failure due to incorrect fitting. The following table shows the conversion from the original size of the fork or frame (without original adapters) to the oversized disc size:
|
Ref. |
Front size (mm.) |
Rear size (mm.) |
Weight (gr.) |
|
SB001 (+43 mm) |
ø160 > ø203 ø180 > ø223 |
ø160 > ø203 ø180 > ø223 |
21 |
|
SB002 (+20 mm) |
ø160 > ø180 ø180 > ø200 ø203 > ø223 |
ø160 > ø180 ø180 > ø200 |
22 |
|
SB003 (+63 mm) |
ø160 > ø223 |
ø160 > ø223 |
29 |
|
SB004 (+23 mm) |
ø180 > ø203
ø200 > ø223 |
ø180 > ø203
ø200 > ø223 |
26 |
|
SB005 (Fox fork 40 & 49) |
ø203 > ø223 |
25 |
CB001: the adaptor allows mounting 6-bolt GALFER Disc Wave® in all Center Lock hubs (not compatible with Fulcrum AFS System, which needs the CB003). It has two mechanical parts of black anodized aluminium and a metal washer to fix the disc. Installation is easy and quick, and you only need the specific removal tool for the outer Center Lock lock ring. Compatible for all wheel hubs, for big (15-20 mm) and small (9 mm) diameters.
SB002 - POSTMOUNT ADAPTER +20 mm.
22 gr.
Applications :
- MTB
- E-BIKES
SB003 - POSTMOUNT ADAPTER +63 mm.
29 gr.
Applications :
- MTB
- E-BIKES
SB004 - POSTMOUNT ADAPTER +23 mm.
26 gr.
Applications :
- MTB
- E-BIKES
SB005 - POSTMOUNT ADAPTER ONLY FOR FOX FORK 40 & 49 (+20mm)
25 gr.
Applications :
- MTB
- E-BIKES
NEW
CB001 - CENTER LOCK ADAPTER
Universal hub, not compatible with Fulcrum AFS System
Applications :
- MTB
- ROAD
- E-BIKES
CB003 - ADAPTER AFS® SYSTEM (FULCRUM)
Only compatible with Fulcrum AFS® System
Applications :
- MTB
- ROAD
- E-BIKES
NEW
MG001 - SPEED SENSOR MAGNET FOR E-BIKES
Applications:
SHIMANO, SPECIALIZED <2018, BROSE, BOSCH, GIANT
Application :
- E-BIKES
NEW
MG002 - SPEED SENSOR MAGNET FOR E-BIKES
Applications:
TREK, SPECIALIZED >2019
NEW
MG003 - INTEGRATED SPEED SENSOR MAGNET FOR E-BIKE
2 gr.
Compatible with:
DB003W, DB003W2, DB003WCL, DB034W, DB034WCL, DB006W, DB006W2, DB022W, DB023W, DB024W, DB027W
Application :
- E-BIKES
BL001 - LIGHTWEIGHT STAINLESS M5 BOLTS FOR STANDARD 6-BOLT DISC SYSTEM
2 gr./u
Applications :
- MTB
- ROAD
- TRIAL
- E-BIKES
- GRAVEL
NEW
BL002 - LIGHT STAINLESS 20 BOLTS PACK M6X16 FOR ADAPTERS
4 gr./u
Applications :
- MTB
- ROAD
- TRIAL
- E-BIKES
- GRAVEL
NEW
95998A02 - BRAKE CLEANER
500 gr.
Bike brake cleaner based on quick evaporating solvents. Quick evaporation and leaves no oily residues. Does not affect rubber, plastic, aluminum and carbon, compatible with all components of your bike.
Applications :
- MTB
- ROAD
- TRIAL
- E-BIKES
- GRAVEL
NEW
